bjorn3 (Apr 21 2022 at 12:07): bjorn3 (Apr 21 2022 at 12:07):The abstract of https://arxiv.org/abs/2011.13127 seems interesting:
Copy-and-Patch Compilation: A fast compilation algorithm for high-level languages and bytecode
[...]
The generated code runs an order of magnitude faster than interpretation and 14% faster than LLVM -O0. Our WebAssembly compiler generates code 4.9X-6.5X faster than Liftoff, the WebAssembly baseline compiler in Google Chrome. The generated code also outperforms Liftoff's by 39%-63% on the Coremark and PolyBenchC WebAssembly benchmarks.
Andy Wingo (Apr 25 2022 at 08:41):i came here to share that too! i think cranelift could be useful to generate a stencil library. could be a nice improvement for baseline compilation in wasmtime
Chris Fallin (Apr 25 2022 at 16:22):It's a really interesting technique, thanks!
David Lloyd (Apr 25 2022 at 16:23):is the full text available anywhere?
Chris Fallin (Apr 25 2022 at 16:25):At the arxiv link above, I think! "PDF" in the right bar
David Lloyd (Apr 25 2022 at 16:26):oh, I missed it. thanks
lqd (Apr 25 2022 at 19:45):in the same area, there's the classic "multi-level quickening" https://arxiv.org/abs/2109.02958
Andy Wingo (Apr 26 2022 at 07:04):better link: http://fredrikbk.com/publications/copy-and-patch.pdf
Sam Parker (Jun 07 2022 at 10:51):@Alexa VanHattum @Chris Fallin continuing this thread, but not quite a paper, there's been some interesting work verification work on the LLVM side of things for aarch64: https://blog.regehr.org/archives/2265
Chris Fallin (Jun 07 2022 at 15:49):Super cool, thank you!
bjorn3 (Sep 13 2022 at 08:00):https://drops.dagstuhl.de/opus/volltexte/2022/15933/pdf/dagrep_v011_i010_p173_21481.pdf
Secure compilation is an emerging field that puts together advances in security, programming languages, compilers, verification, systems, and hardware architectures in order to devise more secure compilation chains that eliminate many of today’s security vulnerabilities and that allow sound reasoning about security properties in the source language. For a concrete example, all modern languages provide a notion of structured control flow and an invoked procedure is expected to return to the right place. However, today’s compilation chains (compilers, linkers, loaders, runtime systems, hardware) cannot efficiently enforce this abstraction against linked low-level code, which can call and return to arbitrary instructions or smash the stack, blatantly violating the high-level abstraction. Other problems arise because today’s languages fail to specify security policies, such as data confidentiality, and the compilation chains thus fail to enforce them, especially against powerful side-channel attacks. The emerging secure compilation community aims to address such problems by identifying precise security goals and attacker models, designing more secure languages, devising efficient enforcement and mitigation mechanisms, and developing effective verification techniques for secure compilation chains.
This seminar strived to take a broad and inclusive view of secure compilation and to provide a forum for discussion on the topic. The goal was to identify interesting research directions and open challenges by bringing together people working on building secure compilation chains, on designing security enforcement and attack-mitigation mechanisms in both software and hardware, and on developing formal verification techniques for secure compilation.
bjorn3 (Sep 16 2022 at 14:45):@Alexa VanHattum https://stefanheule.com/s/projects/strata/ seems relevant for your work on verifying ISLE lowering rules. It has formal semantics for a lot of x86_64 instructions that were semi-automatically discovered. In all cases where the discovered semantics didn't match hand-written semantics, the hand-written semantics were in fact incorrect.
bjorn3 (Oct 04 2022 at 18:59):Not exactly a paper and possibly not all that practical, but https://www.mattkeeter.com/blog/2022-10-04-ssra/ shows a register allocator that is supposedly very fast, but does have some limitations.
Chris Fallin (Oct 04 2022 at 19:04):Interesting write-up for sure; have seen this in LuaJIT before (as they mention) and it's a very effective technique for trace compilers. I don't see any mention of control-flow in the post, and that's one of the confounders for any single-pass algorithm; curious if they have more thoughts on it
bjorn3 (Oct 04 2022 at 19:05):It explicitly mentions that it doesn't work with control-flow. Of course you can always spill everything on any kind of control-flow, but that is probably very flow at runtime.
Amanieu (Oct 04 2022 at 21:40):It also produces sub-optimal results if you have fixed-reg constraints since you only have one pass through the code.
Amanieu (Oct 04 2022 at 21:45):But I guess you could remedy that by adding a pre-processing pass that gathers register hints for each vreg.
Amanieu (Oct 04 2022 at 21:46):It's somewhat like what I had in mind for https://github.com/bytecodealliance/regalloc2/issues/81.
bjorn3 (Jun 24 2023 at 20:20):https://www.cs.cmu.edu/~dkoes/research/CGO08-NOLTIS.pdf looks interesting. It is a near-optimal instruction selector running in linear time.
bjorn3 (Jun 24 2023 at 20:21):(linked from https://lobste.rs/s/p93jau/e_graph_extraction_problem_is_np_complete)
Afonso Bordado (Jun 15 2024 at 21:48):Hydra: Generalizing Peephole Optimizations with Program Synthesis
https://users.cs.utah.edu/~regehr/generalization-oopsla24.pdf
Pretty cool! Bolting this onto souper/souper-harvest would be neat.
fitzgen (he/him) (Jun 18 2024 at 20:47):Afonso Bordado said:
Hydra: Generalizing Peephole Optimizations with Program Synthesis
https://users.cs.utah.edu/~regehr/generalization-oopsla24.pdf
See also https://github.com/bytecodealliance/wasmtime/issues/5783 -- would be great to land those already-generalized-for-us rules as a first step!
bjorn3 (Oct 19 2025 at 12:11):Scaling Instruction-Selection Verification against
Authoritative ISA Semantics
https://dl.acm.org/doi/pdf/10.1145/3764383
The follow up to Crocus from what I can tell.
Chris Fallin (Oct 19 2025 at 22:46):Indeed, and @Michael McLoughlin ‘s talk (freshly given, just yesterday Singapore time) is here: YouTube - - YouTube
Till Schneidereit (Oct 21 2025 at 13:26):so cool! Besides bandwidth, is anything currently blocking us from realizing the CI setup described in section 6.3, where full-coverage verification happens as a recurring scheduled job?
Chris Fallin (Oct 21 2025 at 15:54):The main thing is "merge all of this to main" -- I know that both Michael and Alexa have this on their radars but many other things have also come up. @Michael McLoughlin what's your latest estimate about how the upstreaming work might happen, timeline-wise?
Till Schneidereit (Oct 22 2025 at 14:54):Thanks, that makes sense.
Separate question: are there specific plans to expand coverage? Specifically I'd be interested in coverage of all operations relevant to guest isolation? IIUC that'd entail coverage of IR terms reachable post-optimization, stack operations, and post-wasm-1.0 operations such as those introduced by the Bulk Memory proposal.
Chris Fallin (Oct 22 2025 at 15:26):as far as I know we should cover CLIF opcodes that opt rewrite rules generate as well; I don't know if Michael has specifically analyzed for that though.
Accesses to the stack spill area should be "verified" by the regalloc checker in the sense that the loaded slot number will be verified to have the value expected as stored by a prior store; so no uninitialized reads. The actual stack frame layout and the glue code to convert slot numbers to SP offsets is not part of what the checker sees, nor this isel verifier; that'd be interesting, too. To some degree one needs a whole-function context to validate that, which isn't a good fit for the rule-by-rule SMT verification approach we had here. I think a good solution actually looks something like proof-carrying code, which of course I haven't had the privilege of having time to push forward... someday and/or with the right collaborator!
Till Schneidereit (Oct 23 2025 at 09:39):I was basing the questions on the caveats listed on page 20 of the paper, in section 6.1. Those make it sound as though the opcodes not directly reachable from Wasm, but emitted by rewrites, aren't fully covered yet.
And yes, I've been wondering whether this leaves a gap to be closed by PCC, and that makes sense!
Chris Fallin (Oct 23 2025 at 17:32):Ah, yes, I don't think we specifically know of opcodes that aren't covered that do appear, that was more of a caveat describing what has been evaluated / how the list was obtained.
I would love to get back to PCC and build it out to be robust and usable, too -- this gap bothers me as well :-) Maybe in, like, 2029 or something...
Till Schneidereit (Oct 23 2025 at 17:39):hey, right decade at least :grimacing:
